Focal P20FE Sub Flax Evo Series 8 Inch 4 Ohm Component Subwoofer 250w RMS
Focal P 20FE
Flax Evo Series 8" 4-ohm component subwoofer
Flax to the max
If you've heard Focal speakers, then you know that their reputation for quality is well-deserved. Focal's designers never hesitate to think outside the box when it comes to speaker innovation. To create their Flax Evo Series speakers and subs, for example, they spent five years developing a super-lightweight, extra-rigid cone material made from a layer of flax fibers sandwiched between two layers of glass fibers. You get the warmth of natural fiber combined with the supreme accuracy of a more rigid cone material.
Small size, big sound
Built at Focal's workshop in France, the P 20FE 8" sub delivers performance way beyond its size, using superior materials and construction to handle up to 250 watts RMS. It works equally well in compact sealed or ported enclosures, so it's a great candidate for great bass in a smaller vehicle. If you're putting together a system, make sure to take a look at Focal's component speaker systems that feature the same "Flax Sandwich" cones.
- 8" 4-ohm component subwoofer
- glass fiber/flax/glass fiber laminate cone
- rubber surround
- handles up to 250 watts RMS (500 watts peak)
- frequency response: 39-500 Hz
- sensitivity: 82.5 dB
- top-mount depth: 4-5/8"
- sealed box volume: 0.35-0.53 cubic feet
- ported box volume: 0.35-0.71 cubic feet
- grille not included
Specification
Part Number: P20FE
- Size 8 -inch
- Impedance 4 ohms
- Cone Material Flax/Glass
- Surround Material Rubber
- Ideal Sealed Box Volume (cubic feet) N/A
- Ideal Ported Box Volume (cubic feet) N/A
- Port diameter (inches) 2.75
- Port length (inches) 12
- Free-Air No
- Dual Voice Coil No
- Sensitivity 82.5 dB at 2.83 volts
- Frequency Response 39 - 500 Hz
- Max RMS Power Handling 250
- Peak Power Handling (Watts) 500
- Top Mount Depth (inches) 4 5/8
- Bottom Mount Depth (inches) N/A
- Cutout Diameter or Length (inches) 7 1/8
- Vas (liters) 12
- Fs (Hz) 38.5
- Qts 0.56
- Xmax (millimeters) 10
What's Included
2 Year Warranty
- One 8" Single voice coil subwoofer
- Rubber trim ring/gasket (installed)
- Six 7/8" Screws
