XD600/1v2
Monoblock Class D Subwoofer Amplifier, 600 W x 1 @ 2 Ω / 400 W x 1 @ 4 Ω - 14.4V
This potent monoblock amplifier employs our high-speed NexD™ switching design to achieve unprecedented efficiency and amazing power output in a very compact chassis. Don't let the small size fool you, though... this amplifier is capable of serious subwoofer power, delivering a full 600 W of continuous power into a 2 ohm load (14.4V, 1% THD).
Targeted specifically for subwoofer applications, the XD600/1v2 includes a variable slope low-pass filter with continuously variable cutoff frequency selection from 50-500 Hz.
The XD600/1v2 also features the v2 Spec feature set, which consists of automatic turn-on capability (via signal sensing or DC-offset sensing), and a dual-range differential-balanced input section able to handle a wide range of input voltage levels. With the addition of an HD-RLC remote level control (sold separately), the amplifier's level can be directly controlled from the driver's seat.
This amplifier features a black powder-coat finish and a gasketed, brushed aluminum cover for the controls.
Part Number: XD400/4v2
Specification
- Rated Continuous (RMS) Power @ 14.4 V
- @ 4 Ω 400 W RMS x 1
- @ 3 Ω 500 W RMS x 1
- @ 2 Ω 600 W RMS x 1
- @ 1.5 Ω N/A
- Rated Continuous (RMS) Power @ 12.5 V
- @ 4 Ω 300 W RMS x 1
- @ 3 Ω 400 W RMS x 1
- @ 2 Ω 500 W RMS x 1
- @ 1.5 Ω N/A
- Frequency Response 7 Hz - 500 Hz (+0, -1dB)
- S/N Ratio, referred to highest rated power >87 dB below rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth)
- S/N Ratio, referred to 1 W >67 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
- Damping Factor @ 4 Ω >1000 / 50 Hz
- Damping Factor @ 2 Ω >500 / 50 Hz
- THD+N @ Rated Power <1% @ 2 Ω per Ch.
- Input Voltage Range @ RCA Inputs Switchable from 200 mV - 2 V RMS (Low) to 800 mV - 8 V RMS (High)
- Min.Copper Power / Ground Wire Gauge 4 AWG wire
- Fuse Rating 50 A (AFS, AGU or MaxiFuse™)
- Filter Mode(s) Low-Pass only
- Filter Slope(s) 12/24 dB/octave
- Filter Frequency Range 50 Hz - 500 Hz
- Detented, Calibrated Filter Freq. Potentiometer Yes
- Filter Defeat Function Yes
- Infrasonic Filter 30 Hz, defeatable
- Bass Boost EQ No
- Output Polarity Switch No
- Remote Subwoofer Level Control Optional (HD-RLC)
- Remote Bass EQ Boost Control No
- Pass-Through Preamp Output Buffered
2 Year Warranty
What's Included
- XD600/1v2
